Edit Linear Dimension

Knowledge Base | DynaScape CreatorHelp TopicsBasic CAD: Edit Entities

Edit Linear Dimension

  1. Select the dimension and Edit Dimension tool will launch.

  2. Click on either of the end point of the entity to move it to a new location. Click to confirm the location.

    OR

    Click on the end vertex of the Witness line to change the length.

  3. Click on the canvas to place the Witness line.

  4. The Dimension text of the selected dimension will be displayed accordingly, and you can position the text to either left outside, right outside, middle and top middle.

  5. Right click and select Confirm, click on the check mark in the sidebar, or press Enter, to commit the change.

  6. Press Esc to cancel and close the tool.
