Create Ellipse Arc

Use the Ellipse Arc tool to add an ellipse arc to the drawing.

To Create an Ellipse Arc:

1. Click on the Ellipse Arc tool.

2. Click on the canvas to locate the start and end of the chord. Press Tab to set a value in the dynamic input.

3. Click again to confirm the location of the bulge.

4. Complete the ellipse arc shape by adjusting the bulge.

5. Press Esc or click on the x in the top right corner of the sidebar to cancel and close the tool.
