Selection

To select:

1. Click on an entity or image to select it. Selected items are highlighted.

2. Hold Shift and click on multiple items to select or deselect.

3. Click and drag to use window selection.

   1. If you create a selection window moving from left‐to‐right, only entities entirely within the window are selected. Entities that intersect the window, or that are outside the window are not selected.

   2. When creating a selection window moving from right‐to‐left, only items intersected by the window frame are selected. Entities entirely within the window, or entirely outside the window, are not selected.

4. Press Ctrl+A or right click and select Select All to select all entities and images in the drawing.

Edit Multiple Items will appear in the sidebar. Shared options can be modified for the selected items.
