How to Use Title Blocks

Step 1: Set Up Your Drawing

1. Create a new drawing.

2. Enter your desired properties for Paper Format, Orientation, Scale, Dimension Units and Color Palette.

   (e.g., sheet size: 18x24, orientation: landscape or portrait, scale: 1:4, etc.).

Step 2: Insert the Title Block

1. Click on the Insert Figure tool.

2. In the Sidebar, under Category navigate to the Title Blocks library.

3. Select the title block that matches your sheet size and scale.

4. Click to place it. It will auto-center on your canvas.

Step 3: Fill In Title Block Details

1. Click on the Title Block.

2. In the sidebar, click Parameters.

3. Enter your desired text (e.g., project name, date, etc.).

4. Right-click to confirm or press the Spacebar to apply.

5. Press Esc or click the X in the top right corner of the sidebar to cancel and close the tool.
